Características
Hemos pensado en esta bici enfocándola en como querríamos realizar el ascenso de Paterberg. Es nuestra bicicleta enfocada en aquellos que buscan escalar las cotas más altas.
Diagrama
Medidas
| Talla | 490 | 520 | 540 | 560 | ||
| A | STACK | mm | 480 | 508 | 532 | 546 |
| B | REACH | mm | 371 | 390 | 398 | 410 |
| C | HEAD TUBE LENGTH | mm | 91 | 111 | 131,5 | 151 |
| D | HEAD TUBE ANGLE | o | 72,3 | 73 | 73 | 73,5 |
| E | BB DROP | mm | 68 | 68 | 68 | 68 |
| F | FORK LENGTH FULL | mm | 369 | 369 | 369 | 369 |
| G | FORK RARE/OFFSET | mm | 47 | 47 | 47 | 47 |
| H | FRONT CENTER | mm | 559 | 578 | 585 | 607 |
| I | CHAINSTAY LENGTH | mm | 408 | 408 | 408 | 408 |
| J | TOP TUBE LENGTH HORIZONTAL | mm | 505 | 535 | 551 | 571 |
| K | SEAT TUBE LENGTH | mm | 435 | 455 | 473 | 493 |
| L | SEAT TUBE ANGLE | o | 75,4 | 74 | 73,5 | 73,25 |
| M | WHEELBASE | mm | 957 | 976 | 983 | 1005 |
Especificaciones
| Material | T1000 | |||
| Head tube | 1 1/8" -1/ 1/2" | |||
| CABLE ROUTING | Internal | |||
| BOTTOM BRACKET | BSA | |||
| MAX TIRE | 28 | |||
| BRAKE | Disc Brake | Flat Mount | 140/160 mm | |
| MAX CHAINRING | 55-42T | |||
| SEAT POST | Specific 350 mm lenght*20 mm | |||
| O.L.D. | FORK | 12*100 mm | REAR | 12*142 mm |
| CABLE PLUG | Mechanical and Digital |
Pesos
| FRAME | 1120 gr |
| FORK | 410 gr |
| SEAT POST | 185 gr |
| HANDLEBAR | 380 gr |
