Características
Esta bici gravel es ideal en todo tipo de terrenos; podrás alcanzar los senderos más lejanos. Se desenvuelve muy bien en todo tipo de senderos y es ideal para ascensos prolongados con su grupo SRAM Rival.
Diagrama
Medidas
| Talla | XS | S | M | L | XL | ||
| A | STACK | mm | 537 | 560 | 579 | 600 | 620 |
| B | REACH | mm | 362 | 364 | 373 | 381 | 389 |
| C | HEAD TUBE LENGTH | mm | 110 | 130 | 150 | 170 | 190 |
| D | HEAD TUBE ANGLE | o | 70 | 70,75 | 71 | 71,25 | 71,25 |
| E | BB DROP | mm | 75 | 75 | 75 | 75 | 75 |
| F | FORK LENGTH FULL | mm | 400 | 400 | 400 | 400 | 400 |
| G | FORK RARE/OFFSET | mm | 50 | 50 | 50 | 50 | 50 |
| H | FRONT CENTER | mm | 588 | 591 | 604 | 616 | 631 |
| I | CHAINSTAY LENGTH | mm | 425 | 425 | 425 | 425 | 425 |
| J | TOP TUBE LENGTH HORIZONTAL | mm | 511 | 522 | 539 | 556 | 573 |
| K | SEAT TUBE LENGTH | mm | 420 | 450 | 480 | 500 | 520 |
| L | SEAT TUBE ANGLE | o | 74,5 | 74,25 | 74 | 73,75 | 72,5 |
| M | WHEELBASE | mm | 1002 | 1005 | 1018 | 1030 | 1045 |
Especificaciones
| Material | T1000 | |||
| Head tube | 1-1/2" - 1-1/2" | |||
| CABLE ROUTING | Internal | |||
| BOTTOM BRACKET | T47 | |||
| MAX TIRE | 50 | |||
| BRAKE | Disc Brake | Flat Mount | 140/160 mm | |
| MAX CHAINRING | 46-25T | |||
| SEAT POST | 27,2 mm | |||
| O.L.D. | FORK | 100*12 | REAR | 142*12 |
| CABLE PLUG | Mechanical and Digital |
Pesos
| FRAME | 1250 gr |
| FORK | 450 gr |
| SEAT POST | 140 gr |
| HANDLEBAR | 330 gr |
Comprueba nuestra disponibilidad en tiendaVer modelos GR3
